Product features
1. With high Slew Rate, strong ability to restore the details to get more clear and delicate
high-frequency performance.
2. With high Damping Factor, strong low-frequency control force to make a strong
low-frequency straight extension.
3. The new circuit design, adopts the SMT surface mount technology, to improve the
consistency and efficiency of the machine.
4. H(Class H) circuit design, advanced power supply technology to reduce the overall
power consumption by 40%, reducing the
system heating and the weight of the product.
5. Suitable for: KTV, conference room, multi-function hall, bar and theater.
DSP function
1 .in 2 out, 2 in 2 out, 48Khz sampling frequency DSP module, can be used in active
speakers or power amplifiers
2. Channels can be mixed in random proportions, with equalization, phase, delay,
frequency division, limiting, gain, mute, etc.
3. Each channel has a delay of 8.3ms,input and output 8 parameters balance, support
PEQ,High Shelf,Low shelf EQ
4.Three high and low pass filters Butter-worth, Bessel, Linkwitz-Riley. 12dB,18dB,
24dB adjustable, frequency 1/3 oct stepping.
5.With channel copy function, you can quickly copy and adjust parameters.
6.Digital limiter, start level, start release time are adjustable.
7.Internal resistance white noise generator.
8.With USB, TS485 interface, graphics control software.
 |
